20 Pin Connector Industrial Monitor Display 12.1'' 800*600 Pixels Innoux G121AGE-L03

Product Categories

FOCUS VISION TECHNOLOGY LIMITED

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 20 Pin Connector Industrial Monitor Display 121 800600 Pixels Innoux G121AGEL03
Brand: INNOLUX
Price: 1 USD

Brand Name : INNOLUX

Model Number : G121AGE-L03

Certification : Rohs,CE,FCC

Place of Origin : KOREA

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W, Western Union, MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

material : glass oled

color : 16.7M colors

model : WLED

style : wide screen high resolution 800*600

brightness : 450cd

connector : 20pin

contrast ratio : 1500:1

working life : 50K hours

Contact Now

Brand	Innolux	Model	G121AGE-L03
Diagonal Size	12.1 inch	Type	a-Si TFT-LCD , LCM
Pixel Format	800(RGB)×600 [SVGA]	Configuration	RGB Vertical Stripe
Active Area	246(H)×184.5(V) mm	Outline Dim.	260.5(H)×204(V) ×8.9(D) mm
Bezel Area	249.0(H)×187.5(V) mm	Treatment	Antiglare, Hard coating (3H)
Luminance	450 cd/m² (Typ.)	Contrast Ratio	1500:1 (Typ.) (TM)
View Direction	Symmetry	Response Time	13/12 (Typ.)(Tr/Td)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Operating Mode	Super MVA, Normally Black, Transmissive
Support Color	262K/16.2M 50% (CIE1931)	Light Source	WLED , 50K hours , With LED Driver
Weight	506/530g (Typ./Max.)	Designed For
Frame Rate	60Hz	Touch Panel	Without
Interface Type	20 pins LVDS (1 ch, 6/8-bit) , Connector
Power Supply	3.3/5.0V (Typ.)(VCC)
Environment	Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C

20 Pin Connector Industrial Monitor Display 12.1'' 800*600 Pixels Innoux G121AGE-L03

Innolux Corporation (hereafter called Innolux) G121AGE-L03 is a 12.1 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -30 ~ 85°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Panelook in the following: Antiglare Surface, 6/8 bit Selectable, Wide Viewing Angle, Landscape type, Wide Temperature, Lamp Repaceable, White LED Backlight, Lamp life ≥ 50K hours, U/D,L/R Reverse . Based on its features, Panelook recommend that this model be applied to Industrial, Healthc are etc. According to the information stored in Einklcd this model mass production on Q2, 2013, Now this model is in production. We inputted this model's specification on Apr 8 2013 for the first time, and the latest update on Sep 29 2018. If you want to embed G121AGE-L03 LCM in your future product, Einklcd strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The G121AGE-L03 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

It's 450cd/m2 lcd MODEL for industrial lcd ,computer,all-in-one computer,desktop,laptop lcd.

All our LCD LED screen monitor module panel products will be full test one by one before sending .
