7inch 500cd/m2 Car LCD Display with 30 Pin FPC TFT-LCD Screen for Automotive Applications

Brand Name : auo

Model Number : C070FW02 V0

Certification : Rohs,CE,FCC

Place of Origin : China

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W,Western Union,MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

material : glass oled

color : 262K colors

model : WVGA

style : wide screen high resolution 800*480Pixels

brightness : 300cd

connector : 60

contrast ratio : 400:1

working time : 10k hours

Contact Now

AUO 30 Pin 8" 480x234 76PPI 500cd/m² Car LCD Display C070FW02 V0

The C070FW02 V0 is a 7.0-inch diagonal a-Si TFT-LCD display panel from AU Optronics Corp. featuring an integral CCFL backlight system. This automotive-grade display operates in temperatures from -30°C to 75°C and withstands vibration levels up to 2.9G (28.4 m/s²).

Key Features

• 7.0-inch diagonal display with 480*234 pixel resolution

• 76 PPI pixel density with 500 cd/m² luminance

• Wide operating temperature range: -30°C to 75°C

• High vibration resistance: 2.9G (28.4 m/s²)

• 300:1 contrast ratio with 12/18ms response time

• TFT-specific analog RGB 30-pin FPC interface

Technical Specifications

Brand: AUO

Model: C070FW02 V0

Display Type: a-Si TFT-LCD, LCM

Active Area: 154.08*86.58 mm

Outline Dimensions: 164.9*100*6 mm

Pixel Format: 480(RGB)*234, 76PPI

Luminance: 500 cd/m² (Typ.)

Contrast Ratio: 300:1 (Typ.)

Viewing Angle: 60/60/60/40 (CR≥10)

Response Time: 12/18 ms (Tr/Td)

Operating Mode: TN, Normally White, Transmissive

Light Source: CCFL [1 pcs], 10K hours

Interface: TFT Specific Analog RGB 30 pins FPC

Power Supply: 5/5/15/-10V (VCC/AVDD/VGH/VGL)

Weight: 160±10g

Surface Treatment: Antiglare (Haze 25%)

Environmental Specifications

Parameter	Specification
Operating Temperature	-30°C to 75°C
Storage Temperature	-40°C to 85°C
Vibration Level	2.9G (28.4 m/s²)

Note: This model entered mass production in Q1 2006 and is currently discontinued. For integration into future products, contact AUO or their agent for the latest production and specification details.
